Formati compatibili
DSD (DSF, DFF), WAV, FLAC, AIFF, ALAC, M4A, APE and others
Velocità di bit e campionamento
PCM up to 768kHz/32bit. DSD up to 256 DoP. Native DSD up to 512(Internal play only)
HDD per la memorizzazione della libreria musicale
10TB 3.5″ X 1 HDD
SSD per sistema e cache 480GB M.2 NVMe
480GB M.2 NVMe
DAC Chipset
AKM AK4497 Dual-Mono Design with Dual-Mono Linear Power Supplies
Alimentazione Full-Linear
Full-Linear
Display
8.8″ 1920 x 480 WIDE IPS COLOR LCD
Ingresso audio digitali
1 x RCA SPDIF / 1 x BNC SPDIF / 2 x TOSLINK up to 24-bit / 192 kHz / DOP up to DSD64
Porta USB
2 x USB 3.0 (Rear)
Porta USB audio dedicata
1 x USB AUDIO Class 2.0
Ethernet
1 x Double-Isolated Gigabit Ethernet
Controllo del volume
-90 dB – 0dB, 0.5 dB step, Velocity Sensitive Operation Variable output control from front panel rotary knob, Conductor App and supplied IR remote control when used as preamplifier
Struttura del Clock
Revised Full Differential System
Uscite cuffie
1 x 4pin XLR Balanced / 1 x 4.4mm Balanced / 1 x 6.5mm Unbalanced
CD Ripping
TEAC Slot-Load CD-ROM Drive Automated ripping support for Arconova Nimbie Autoloader via USB 3.0 port (optional)
Clock accuracy principale
OCXO Based Precision Jitter Reducing Clock Generator
CPU
Intel N4200 Quad Core
UPS interno
Super Capacitor Based UPS (uninterrupted power supply)
Uscita USB Audio
PCM: Up to 32bit / 768kHz – DSD: DoP Up to 128- Native DSD Up to 256
Uscita audio analogiche
Unbalanced (RCA): 2.0 or 2.7 Vrms / Balanced (XLR): 4.0 or 5.4 Vrms selectable
Dimensione (WHD) e peso
16.93 x 5.6 x 14.0 in., 37.5 lbs. / 430 x 141 x 355 mm., 17 Kg.
