Peso
49lbs / 22.2 kg
Dimensioni
18.9 x 15 x 11.1” / 48 x 38 x 28cm
Telaio
Machined Aluminum
Colori
Nickel, Champagne, Black
Operating Voltage
100V / 115V / 230V / 50-60Hz
Consumo energetico(Operation / Standby)
160W / 0.3W
Mains Fuse
2A slow-blow
Electron Tube Complement
One Matched Pair Western Electric 300B, 2x ECC81
Phono MM Sensitivity (10W / 4Ω)
0.75mV
Phono MC Sensitivity (10W / 4Ω)
70μV
CD Sensitivity (10W / 4Ω)
0.27V
Impedenza di ingresso CD
20 kOhms
Impedenza di ingresso Phono MM
47 kOhms | | 100 pF
Impedenza di ingresso MC
1000 kOhms
SNR MM (10W / 4Ω, input 5mV)
83 dB(A)
SNR MC (10W / 4Ω, input 0.5mV)
73 dB(A)
SNR CD (10W / 4Ω, input 0.5V)
101 dB(A)
Risposta in frequenza CD
15 Hz - 32 kHz (-3 dB)
Phono risposta in frequenza
30 Hz - 20 kHz (RIAA within +/- 0.5 dB)
Output Power / 4 Ω / THD 10%
2 x 20 watts
Output Power / 4 Ω / THD 5%
2 x 16 watts
Output Power / 4 Ω / THD 3%
2 x 14 watts
Output Power / 8 Ω / THD 10%
2 x 20 watts
Output Power / 8 Ω / THD 5%
2 x 16 watts
Output Power / 8 Ω / THD 3%
2 x 14 watts
BT Standard
v4.2
BT Codecs
BC, MP3, AAC, Fastream, APTX
BT Sample Rate (adaptive)
Up to 96kHz / 16-bit
BT risposta in frequenza
20 Hz - 20 kHz
BT SNR
96dB
